Southwire C10M Type C Conduit Body 4 Inches

Product Description

The SOUTHWIRE C10M is a 4-inch malleable iron rigid threaded Type C conduit body designed for use in electrical raceway systems. Type C conduit bodies provide a straight-through pull point at both ends, allowing conductors to be pulled or spliced without disassembling the raceway. The malleable iron construction provides durability in demanding environments, including industrial and commercial installations. Licensed electricians typically install this fitting as part of rigid metal conduit (RMC) or intermediate metal conduit (IMC) systems where code-compliant access points are required.

This conduit body is suited for commercial and industrial electrical installations where 4-inch rigid threaded conduit runs require a mid-run access point. Typical applications include long conduit runs, wire pulls through exposed or concealed raceway systems, and locations where future conductor access is anticipated. The Type C body configuration aligns entry and exit on the same axis, making it appropriate for straight runs requiring a pull point.

Key Features

• Malleable iron construction for strength and resistance to mechanical stress
• Rigid threaded ends for secure connection to RMC and IMC conduit systems
• Type C configuration provides straight-through access for conductor pulls and splices
• 4-inch trade size accommodates large-conductor installations in commercial and industrial settings
• Removable cover plate allows access to conductors after installation

Compatibility

Designed as an OEM-style fitting for use with 4-inch rigid metal conduit and intermediate metal conduit threaded raceway systems in commercial and industrial electrical installations.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize all circuits before opening the conduit body or pulling conductors. Use appropriate thread sealant or conduit thread compound when making up threaded joints to ensure a secure, weathertight connection. Do not exceed the conduit body fill capacity as determined by NEC fill calculations for the conductor sizes being installed.

Technical Specifications

• Trade Size: 4 inches
• Body Type: Type C
• Material: Malleable Iron
• Conduit System: Rigid Threaded
• UPC: 751338200548

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: C10M
