Southwire A50039-1A 16-19 Cu 2/C OAS CMR/CMG/CL3R/FPLR PVC 300V 1000 ft

Product Description

The Southwire A50039-1A cable is a 16 AWG, 2-conductor, overall shielded (OAS) cable with PVC insulation and a PVC jacket, supplied in a 1000 ft length. This 300 Volts AC cable is designed for use in remote control, signaling, and power-limited circuits, and can also be used as communication circuits. It is suitable for security, sound and audio, speaker, public address, intercom, sound reinforcement, alarm, and access control applications.

• Designed for remote control, signaling, and power-limited circuits per NEC Article 725.
• Suitable for communication circuits per NEC Article 800 (for 16 AWG and smaller).
• Applicable for security, sound, audio, speaker, public address, intercom, sound reinforcement, alarm, and access control systems.

Product Highlights

UL 1666 flame test compliant, sunlight resistant, and includes a rip cord for easy installation.

Product Information

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: A50039-1A
• Country of Origin: United States

Technical Specifications

• Cable Type: CMR/CL3R/FPLR/CMG Multi-Conductor Shielded
• Conductor Size: 16 AWG
• Number of Conductors: 2
• Conductor Type: Bare Stranded Copper
• Conductor Material: Stranded bare copper per ASTM B3 and B8
• Strands: 19
• Insulation Material: Polyvinyl Chloride (PVC)
• Jacket Material: Polyvinyl Chloride (PVC)
• Jacket Color: GRAY
• Shielding Material: Aluminum foil shield with 24 AWG tinned drain wire
• Rip Cord: Yes
• Length: 1000 ft
• Voltage Rating: 300 Volts AC
• Minimum Operating Temperature: -10°C
• Maximum Operating Temperature: 60°C
• DC Resistance at 25C: 4.181 ohms/1000' (6.22 ohms/km)
• AC Resistance at 75C: 5.037 ohms/1000' (7.50 ohms/km)
• Inductive Reactance: 0.033 ohms/1000' (0.05 ohms/km)
• Series: 31SR
• RoHS Compliant: Yes
• NEC Compliant: Yes
• UL 444: Yes
• UL 13: Yes
• Flame Test: UL 1666
• Sunlight Resistant: Yes
