Southwire 962385501 low voltage burglar wire 22 AWG 4 conductors 500 foot

Product Description

The SOUTHWIRE 962385501 is a low voltage burglar wire, featuring 22 AWG solid copper with 4 conductors. This non-shielded cable is rated CM/CL2/FT1, making it suitable for burglar alarm and power limited circuits. It is designed for interconnecting burglar alarm systems to control panels and for general purpose communication applications. The cable has a Polyvinyl Chloride (PVC) jacket and is 500 feet in length.

• 22 AWG, 4-conductor solid copper construction.
• CM/CL2/FT1 rated for burglar alarm and power limited circuits.
• Non-shielded cable, 500 feet in length.

Product Highlights

Ideal for burglar alarm systems, power limited circuits, and general communication applications, offering robust 22 AWG solid copper connectivity.

Product Information

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: 962385501
• Country of Origin: United States

Technical Specifications

• Manufacturer Part Number: 962385501
• Brand: Southwire
• Manufacturer: Southwire
• AWG: 22
• Conductor Count: 4
• Conductor Material: Solid Copper
• Conductor Stranding: Solid
• Shielding: Non-Shielded
• Cable Type: Burglar Alarm, Power Limited Circuit Cable
• Ratings: CM/CL2/FT1
• Jacket Color: White
• Length: 500 ft
• Conductor Diameter: 0.025 in (0.06 cm)
• Internal Conductor Colors: Black, Red, Yellow, Green
• Insulation Thickness: 6 mils (0.15 mm)
• Approximate Outer Diameter: 0.117 in (0.30 cm)
• Copper Weight: 7 lbs/1000 ft (10 kgs/km)
• Approximate Weight: 12 lbs/1000 ft (18 kgs/km)
• Insulation Material: Foam Polypropylene
• Jacket Material: Polyvinyl Chloride (PVC)
• Voltage Rating: 300V AC
• Sunlight Resistant: Yes
• Plenum Rating: Non-Plenum
