Southwire 56370701 10/2 Submersible Pump Wire 600V 1000 Feet

Product Description

The SOUTHWIRE 56370701 is a 10/2 twisted submersible pump wire with ground, built for direct use in water well installations. Rated at 600 volts and 75 degrees F continuous operation, this cable features solid copper conductors wrapped in moisture-resistant PVC insulation. The twisted conductor configuration reduces electromagnetic interference and meets the physical demands of submersible environments. Sold per 1000-foot roll, it is the industry standard for electrical submersible pumping (ESP) water systems. Licensed electricians and well pump contractors install this cable in residential, farm, and industrial water well applications.

This cable is suited for both grounded and ungrounded water well cable systems where a moisture-resistant, code-compliant conductor is required. The 10 AWG sizing handles the load demands of residential and light commercial submersible pump motors. It is commonly pulled through well casing during new pump installations or replacement service calls. The unjacketed design keeps the cable profile slim for tight well casing clearances, and the colored conductors aid in proper termination at the pump control box and disconnect.

Key Features

• 600V rated with moisture-resistant PVC insulation for submersible well environments
• Twisted conductor configuration meets industry standards for ESP water systems
10 AWG solid copper conductors sized for residential and farm submersible pump loads
• Includes ground conductor for compliance with NEC submersible pump grounding requirements
• Supplied without outer jacket to reduce diameter for tight well casing installations
• Listed to UL Standard 83

Compatibility

Designed for use in residential, farm, and industrial water well applications with grounded and ungrounded submersible pump cable systems that require 10/2 with ground wire meeting NEC and UL Standard 83 requirements.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC Article 680 and applicable local codes for water well pump wiring. Disconnect and lock out all power at the service panel and pump control box before handling any conductors. Verify conductor color assignments at the control box and pump motor before making terminations. Do not exceed the cable voltage rating or expose the conductors to chemicals or abrasion outside of their rated submersible application.

Technical Specifications

• Voltage Rating: 600 volts
• Temperature Rating: 75 degrees C
• Wire Gauge: 10 AWG
• Configuration: 2 conductors with ground (10/2 with ground)
• Conductor Type: Solid copper
• Insulation: Moisture-resistant PVC
• Cable Length: 1000 feet per roll
• Listing: UL Standard 83
• Jacket: None (unjacketed)

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: 56370701
