Product Description
The SOUTHWIRE 28827421 Wire 14/2-NMWG is a non-metallic building wire with a 25 feet length. It is primarily used in residential wiring as branch circuits for outlets, switches, and other loads. The cable may be run in air voids of masonry block or tile walls where such walls are not wet or damp locations.
- Gauge: 14.0
- Material: Copper
- Number of wires: 2
Product Highlights
This wire is designed for residential wiring and can be used in dry locations. It features copper conductors and a white color-coded jacket for size identification.
Product Information
Standard Information
-
Brand: SOUTHWIRE
-
Manufacturer Part Number: 28827421
Technical Specifications
-
Gauge: 14.0
-
Material: Copper
-
Number of wires: 2
-
Brand: Southwire
-
Manufacturer: Southwire
-
Model / MPN: 28827421
-
MPN: 28827421
-
Number of Items: 1.0
-
Product Group: Home Improvement
-
Product Type: ELECTRONIC_WIRE
-
Size: 25' 14/2
-
Total Wire Length (ft.): 25 ft
-
Cond. Size: 14 AWG
-
Conductor Number: 2
-
Cond. Strands: Solid
-
Diameter Over Conductor (in): 0.064 inch
-
Diameter Over Conductor (cm): 0.16 cm
-
Insulation Thickness (mils): 20 mils
-
Insulation Thickness (mm): 0.51 mm
-
Ground Size: 1x14
-
Jacket Thickness (mils): 25 mils
-
Jacket Thickness (mm): 0.64 mm
-
Approx. OD (in): 0.372 x 0.176 inch
-
Approx. OD (cm): 0.94 x 0.45 cm
-
Copper Weight (lbs/1000'): 37 lbs/1000'
-
Copper Weight (kgs/km): 55 kgs/km
-
Approx. Weight (lbs/1000'): 61 lbs/1000'
-
Approx. Weight (kgs/km): 91 kgs/km
-
Cable Type: NM-B
-
Jacket Color: White
-
Jacket Material: Nylon
-
Manufacturer Part Number: 28827421
-
Numeric ID: 2510412
-
Wire Size: 14 AWG
-
Type: Electronic Wire
-
Sheath Color: White
-
Voltage: 600 V
-
Current Rating: 15 A
-
Conductor Material: Copper
-
Item Length: 25 ft
-
Resistance Properties: Heat Resistant
-
Wire Gauge: 14 AWG
-
Cable Length (Feet): 25
-
Color: White
