Southwire 2549SW0022 Outdoor Extension Cord 100 Ft 12/3 Awg

Product Description

The SOUTHWIRE 2549SW0022 is a 100-foot, 12/3 AWG outdoor extension cord rated for 15 amps at 125 volts AC. Built with SJTW jacket construction, it is designed to handle demanding outdoor environments where flexibility and moisture resistance are required. The three-conductor, 12-gauge build supports tools and equipment with higher current draw without excessive voltage drop over the full 100-foot run. It ships in a two-tone yellow and purple jacket for high visibility on job sites. Licensed electricians, HVAC technicians, and general contractors reach for this cord when powering equipment at a distance from a standard 15-amp outlet.

This extension cord is suited for outdoor residential and light commercial applications. Typical use cases include powering portable compressors, job-site lighting, power tools, and temporary service equipment during construction, service calls, or outdoor events. The 12-gauge conductor size makes it appropriate for loads up to 15 amps across the full 100-foot length, reducing heat buildup and voltage drop that thinner cords experience at this distance. A single NEMA 5-15R receptacle at the load end accepts standard three-prong plugs.

Key Features

• 12/3 AWG conductor set supports 15-amp loads over a full 100-foot run with reduced voltage drop
• SJTW jacket rated for outdoor use with moisture and temperature resistance
• NEMA 5-15P plug and 5-15R receptacle for compatibility with standard 15-amp, 125-volt circuits
• High-visibility yellow and purple jacket increases cord awareness on active job sites
• UL Listed and CSA Certified, meeting OSHA job-site requirements

Compatibility

Designed for use with any NEMA 5-15P outlet supplying 125 volts AC at up to 15 amps. Accepts three-prong NEMA 5-15 plug equipment at the load end.

Installation Notes

Extension cords of this type are installed by electricians, HVAC technicians, or qualified tradespeople following NEC guidelines for temporary wiring. Inspect the jacket for cuts or abrasion before each use and do not deploy a damaged cord. Do not coil tightly under load, as heat buildup can occur in tightly wound conductors. Ensure the circuit supplying the cord is protected by a 15-amp overcurrent device and that the connected load does not exceed the cord rating.
