Southwire 18-8 Thermostat Cable General Purpose 150 Volts 18 AWG 8 Conductors

Product Description

The SOUTHWIRE 18-8 Thermostat Cable is a general-purpose cable designed for various installations. It features bare copper conductors for excellent conductivity and low voltage drop, polypropylene insulation, and a durable PVC jacket. Rated for 150 Volts and temperatures from -20 °C to 75 °C, this 18 AWG cable with 8 conductors is suitable for metal raceways and solid bottom metal cable trays, and is sunlight resistant.

• Bare Copper conductors ensure excellent conductivity and minimal voltage drop.
• Features polypropylene insulation and a durable PVC jacket for protection.
• Includes a rip cord for efficient jacket stripping and sequential length marking.

Product Highlights

General purpose thermostat cable with bare copper conductors, polypropylene insulation, and PVC jacket, rated for 150 Volts and -20 °C to 75 °C.

Product Information

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: 18-8

Technical Specifications

• Conductor Size: 18 AWG
• Number of Conductors: 8
• Conductor Stranding: Solid
• Shielding: Unshielded
• Weight (lbs/1000ft): 33
• Weight (kg/km): 49
• Conductor Material: Bare Copper
• Insulation Material: Polypropylene
• Jacket Material: PVC
• Voltage Rating: 150V
• Temperature Rating: -20°C to 75°C
