Southwire 1703 Emt 1-hole Strap Steel 1 Inch

Product Description

The SOUTHWIRE 1703 is a steel, one-hole EMT strap designed to secure 1-inch electrical metallic tubing to walls, ceilings, and structural surfaces. This type of conduit strap is a standard fastening component used in commercial and residential electrical installations wherever EMT conduit must be supported at regular intervals per NEC requirements. The single-hole mounting design allows for quick, single-fastener attachment to wood, concrete, or metal substrates. Steel construction provides the rigidity and durability required for exposed or in-wall conduit runs in both indoor and light commercial environments.

This strap is suited for use in electrical rough-in work where 1-inch EMT conduit support is required along stud bays, joists, and structural members. Electricians use these straps during conduit installation on commercial build-outs, industrial runs, and residential service work. They are a standard consumable item on any job requiring supported EMT runs over a distance, and are typically installed in multiples along a conduit path to meet code-mandated support spacing intervals.

Key Features

• Fits 1-inch EMT conduit for a secure, snug hold
• Single-hole mounting for fast, single-fastener installation
• Steel construction for strength and durability on conduit runs
• Compatible with standard wood, concrete, and metal mounting surfaces
• Low-profile design keeps conduit close to the mounting surface

Compatibility

Designed as an OEM-style replacement and standard-fit strap for 1-inch EMT conduit systems in residential and commercial electrical installations.

Installation Notes

Installation is performed by licensed electricians following NEC support and securing requirements for EMT conduit. Power to the circuit or panel section must be shut off before working on or near any conduit carrying conductors. Straps are fastened using screws or anchors appropriate for the substrate material. Follow local code requirements for maximum conduit support spacing intervals.

Technical Specifications

• Conduit Type: EMT (Electrical Metallic Tubing)
• Conduit Size: 1 inch
• Mounting Holes: 1
• Material: Steel

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: 1703
