Southwire 105I 1-1/2 in 90-degree Insulated Flex Conduit Connector

Product Description

The SOUTHWIRE 105I is a 1-1/2 inch 90-degree insulated throat flexible conduit connector designed for securing flexible metal conduit to electrical enclosures, junction boxes, and panel knockouts. The 90-degree body angle allows the conduit to exit perpendicular to the box surface, reducing stress on the conduit at the termination point. The insulated throat protects wire insulation from abrasion where conductors pass through the fitting. This type of connector is installed by licensed electricians during rough-in and finish wiring on commercial and residential electrical systems.

This connector is suited for applications where flexible conduit must transition into an enclosure at a right angle, including motor connections, HVAC equipment wiring, and panel feed drops where a straight connector would create a tight bend radius. The 1-1/2 inch trade size accommodates standard flexible metal conduit of the same nominal diameter. It is commonly used in commercial construction, light industrial installations, and equipment service work where code-compliant flexible whip terminations are required.

Key Features

• 90-degree body angle reduces conduit bend stress at box entry points
• Insulated throat protects conductor insulation from abrasion at the fitting edge
• 1-1/2 inch trade size fits standard flexible metal conduit of the same nominal size
• Designed for termination into standard knockout openings on electrical enclosures and panels
• Compact fitting profile suited for tight installation spaces

Compatibility

Designed as an OEM-style fitting for use with 1-1/2 inch trade size flexible metal conduit in standard electrical enclosure knockouts per NEC installation requirements.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize all circuits and lock out the panel before beginning work at any enclosure. Ensure the knockout size matches the 1-1/2 inch trade size of the connector before securing the locknut. Do not over-tighten the connector body in a way that cracks the insulated throat insert.

Technical Specifications

• Trade Size: 1-1/2 inches
• Body Angle: 90 degrees
• Throat Type: Insulated
• Weight: 5 pounds
• UPC: 75133810391

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: 105I
