Southwark Metal 137ND23272 Galvanized Drain Pan 32 Inches X 72 Inches 2 Inches Deep No Drain 24 Gauge

Product Description

The Southwark Metal 137ND23272 is a heavy-duty galvanized drain pan designed for use under air handlers and furnaces with coils. It measures 32 inches wide by 72 inches long and stands 2 inches deep, giving it enough capacity to catch condensate and protect the surrounding structure from water damage. This pan is built from hot-dipped galvanized steel meeting ASTM A653 CS Type B standards, which means it resists rust and corrosion in humid HVAC environments. The 24-gauge steel construction provides solid rigidity for large-span installations. At this size, 24 gauge is the correct specification, as units up to 75 inches use 26 gauge while larger pans require the heavier 24-gauge material for structural integrity. This pan ships without a drain connection, making it a no-drain configuration suitable for installations where condensate management is handled externally or where a drain fitting will be field-installed. Folded corners add strength and help contain any water that accumulates inside the pan. HVAC technicians and installers working on larger residential or light commercial systems will find this pan fits long air handler platforms where standard-width pans fall short. Made in the USA, this product also carries a Prop 65 designation. The pan weighs approximately 16.4 pounds and is sold as a single unit. Whether you are replacing an old rusted pan or installing a new system, this Southwark Metal drain pan delivers the size, gauge, and material quality needed for reliable long-term performance in demanding HVAC applications.

• Hot-dipped galvanized steel construction per ASTM A653 CS Type B for corrosion resistance
• Large 32 inches x 72 inches footprint accommodates oversized air handlers and furnaces with coils
• Folded corners and 24-gauge steel provide structural strength across the full pan length

Product Highlights

The Southwark Metal 137ND23272 drain pan delivers a large-format, heavy-gauge galvanized solution for protecting HVAC installations from condensate damage. Its no-drain design and robust steel construction make it a dependable choice for professional HVAC installers.

Product Information

Standard Information

• Brand: SOUTHWARK METAL
• Manufacturer Part Number: 137ND23272

Technical Specifications

• Size: 32 inches x 72 inches
• Depth: 2 inches
• Gauge: 24 GA
• Material: Hot-Dipped Galvanized Steel per ASTM A653 CS Type B
• Galvanized: Yes
• Drain Connection Quantity: 0
• Drain Connection Size: No Drain
• For Use With: Air Handler or Furnace with Coil
• Weight: 16.394 pounds
• Country of Origin: USA
• Prop 65: Yes
• Unit of Measure: Each
