Southwark Metal 137ND23050 Galvanized Drain Pan No Drain 30 Inches X 50 Inches 2 Inches Deep 24 Gauge

Product Description

The Southwark Metal 137ND23050 is a galvanized steel drain pan designed for use beneath air handlers and furnaces with coils. It provides a reliable secondary containment solution to catch condensate and prevent water damage to floors, ceilings, and mechanical rooms. HVAC technicians and installers use drain pans like this one as a standard part of any split system or air handler installation where moisture accumulation is a concern. This model measures 30 inches wide by 50 inches long and stands 2 inches deep, giving it enough capacity to hold condensate between service intervals or in the event of a primary drain blockage. The pan is constructed from hot dipped galvanized steel per ASTM A653 CS Type B, which provides strong corrosion resistance in humid mechanical environments. At 24 gauge, this pan meets the material thickness standard required for units spanning 76 inches or longer, making it a heavier duty option suitable for larger equipment installations. The corners are folded for added structural integrity, which helps the pan hold its shape and maintain a watertight profile over time. This is a no drain configuration, meaning there is no pre-punched or threaded drain connection installed in the pan itself. HVAC professionals working in applications where a drain connection is not needed, or where field modifications will be made, will find this design straightforward and adaptable. The pan weighs approximately 7 pounds and is manufactured in the USA. It is sold individually and ships as a single unit. This drain pan is a practical, code-compliant accessory for residential and light commercial HVAC installations requiring secondary condensate containment.

• Constructed from hot dipped galvanized steel per ASTM A653 CS Type B for corrosion resistance in humid environments
• Measures 30 inches x 50 inches with a 2 inch depth for reliable condensate containment under air handlers and furnaces with coils
• Folded corners add structural rigidity and help maintain a watertight seal throughout the life of the installation

Product Highlights

The Southwark Metal 137ND23050 is a heavy duty 24 gauge galvanized drain pan built for larger HVAC installations requiring secondary condensate containment. Its no drain design and ASTM-rated steel construction make it a dependable choice for professional installers.

Product Information

Standard Information

• Brand: SOUTHWARK METAL
• Manufacturer Part Number: 137ND23050

Technical Specifications

• Size: 30 inches x 50 inches
• Depth: 2 inches
• Gauge: 24 GA
• Material: Hot Dipped Galvanized Steel, ASTM A653 CS Type B
• Galvanized: Yes
• Drain Connection Quantity: 0
• For Use With: Air Handler or Furnace with Coil
• Weight: 7 pounds
• Country of Origin: USA
• Prop 65: Yes
