Source1 dt-4jr7535u Dual Run Capacitor 35/7.5 Mfd 440V Round

Product Description

The Source1 dt-4jr7535u is a dual run capacitor designed for use in residential and commercial HVAC systems. It provides the continuous electrical boost that motors need to run efficiently after startup. This capacitor supports both the compressor and the fan motor in a single round unit, making it a common replacement part for split systems, heat pumps, and packaged units. HVAC technicians rely on dual run capacitors like this one to restore proper motor function when systems short cycle, fail to start, or draw excessive current. The dt-4jr7535u is rated at 35 plus 7.5 microfarads, meaning the 35 MFD side supports the compressor motor and the 7.5 MFD side supports the condenser fan motor. The 440 volt AC rating makes it compatible with standard single-phase residential and light commercial equipment, and it also works as a direct replacement in systems rated at 370 volts, giving technicians added flexibility in the field. The oil-filled construction provides stable capacitance across a wide operating temperature range of -40 to 70 degrees Celsius, helping the capacitor hold up in hot attic installations, rooftop units, and outdoor condensing units exposed to summer heat. The round shape is the industry-standard form factor for HVAC run capacitors, fitting most existing mounting brackets without modification. Quick connect terminals allow for fast, clean installation with standard blade connectors. A tight 5 percent tolerance ensures the capacitor delivers consistent microfarad output, which protects motors from undervoltage stress and heat buildup. This is a reliable, code-compliant replacement capacitor for York, Coleman, Luxaire, and other Source1-compatible equipment.

• Dual run capacitor rated 35 plus 7.5 MFD supports both compressor and condenser fan motor in one unit
• 440V AC rating is compatible with most single-phase residential and commercial HVAC systems, including 370V equipment
• Oil-filled, round design with quick connect terminals and 5 percent tolerance for dependable long-term motor performance

Product Highlights

The Source1 dt-4jr7535u dual run capacitor is a field-ready replacement for HVAC compressor and fan motor circuits, offering wide voltage compatibility, a standard round form factor, and quick connect terminals for efficient installation.

Product Information

Standard Information

• Brand: SOURCE1
• Manufacturer Part Number: dt-4jr7535u

Technical Specifications

• Capacitance: 35 plus 7.5 uF
• Voltage: 440V AC
• Frequency: 60 Hz
• Run/Start: Run
• Single/Dual: Dual
• Shape: Round
• Terminal Type: Quick Connect
• Tolerance: 5 percent
• Temperature Rating: -40 to 70 degrees Celsius
• Material: Oil Filled
