Source1 2426037000 Run Dual Capacitor 80/5 Mfd 370V Round

Product Description

The Source1 2426037000 is a dual run capacitor rated at 80/5 MFD and 370 volts in a round form factor. It is designed for use in residential and light commercial HVAC systems where two separate capacitance values are needed in a single unit. Dual run capacitors are a common component in split-system air conditioners and heat pumps. They provide continuous electrical support to two motors at once, typically the compressor motor and the condenser fan motor. This eliminates the need for two separate single run capacitors and saves space inside the unit. The 80 MFD side supports the compressor, which is the largest load in the system. The 5 MFD side supports the condenser fan motor. Both sections operate together from a single shared common terminal. The 370-volt rating means this capacitor is compatible with standard single-phase 208 to 240-volt HVAC equipment. Round capacitors like this one fit a wide variety of condensing unit configurations and are among the most frequently replaced components in the field. Run capacitors work by keeping a phase shift in the motor windings, which allows the motor to maintain torque and run efficiently during normal operation. When a run capacitor fails, symptoms include a humming compressor that will not start, a condenser fan that runs slowly, or a system that trips the breaker. Replacing the capacitor quickly restores proper motor function and prevents further damage to the compressor or fan motor. The Source1 2426037000 is a reliable replacement option for HVAC technicians handling routine service calls, planned maintenance, or emergency repairs. Its round housing and dual MFD rating make it a versatile stocking item for service vans and supply houses.

• Dual run capacitor supports both the compressor and condenser fan motor from a single unit
• Rated 80/5 MFD at 370 volts for compatibility with standard single-phase 208 to 240-volt HVAC systems
• Round form factor fits a wide range of residential and light commercial condensing units

Product Highlights

The Source1 2426037000 dual run capacitor delivers reliable electrical support to compressor and condenser fan motors in a compact round package. It is a straightforward, field-ready replacement for HVAC service professionals.

Product Information

Standard Information

• Brand: SOURCE1
• Manufacturer Part Number: 2426037000

Technical Specifications

• Capacitor Type: Dual Run
• Capacitance Rating: 80/5 MFD
• Voltage Rating: 370V
• Shape: Round
