SOURCE 1 S1-02425913700 Condenser Fan Motor - 1/3 HP - 460V - S1-02425913700

Product Description

The SOURCE 1 S1-02425913700 is a condenser fan motor designed for air conditioning systems. It operates at 460 volts and delivers 1/3 horsepower at 1,100 RPM. This single-phase motor features a 48 NEMA frame and rotates clockwise when viewed from the end opposite the shaft.

• Designed for York, Coleman, Evcon, and Luxaire HVAC systems.
• Functions as a direct replacement for part numbers S1-02425913700 and 024-25913-700.
• Operates at 1,100 RPM to enable efficient air circulation in condenser units.

Product Highlights

The SOURCE 1 S1-02425913700 enhances air flow and efficiency in various HVAC applications.

Product Information

Standard Information

• Brand: SOURCE 1
• MPN: S1-02425913700

Technical Specifications

• Bearing Type: Sleeve
• Description: MTR,COND
• Enclosure: Open End Bell Opposite Shaft
• HP: 1/3
• NEMA Frame: 48
• Phase: Single
• RPM: 1,100
• Rotation: Clockwise End Opposite Shaft
• Speeds: 1
• Volts: 460
• Weight: 15.0 lbs
