Sony 9-301-025-91 Led Board CG1 Swf HTB600

Product Description

The SONY 9-301-025-91 is an OEM LED board assembly designed for use in Sony consumer electronics systems. This board provides the LED indicator and signaling functions integral to the unit it supports, delivering reliable status communication within the device. Replacement of a failed LED board restores proper system indication and front-panel feedback. Installation is typically performed by qualified electronics technicians or authorized service professionals familiar with Sony consumer electronics assembly practices.

This LED board is identified as a CG1 SWF assembly and is associated with the HTB600 system. It serves as a direct OEM replacement part within the Sony parts and accessories ecosystem, suited for service depots and technicians performing component-level repairs on compatible Sony consumer electronics units.

Key Features

• OEM Sony LED board assembly for component-level replacement
• CG1 SWF board configuration as specified by Sony
• Associated with the HTB600 platform
• Direct factory replacement part for restoring LED indicator functionality

Compatibility

Compatible with the Sony HTB600 system as indicated by manufacturer part data. Verify fitment against the unit service manual before installation.

Installation Notes

Installation should be performed by a qualified electronics technician familiar with Sony consumer electronics service procedures. Disconnect and fully power down the unit before accessing internal components to eliminate risk of electrical shock or board damage. Use appropriate ESD precautions when handling the LED board to prevent electrostatic damage. Refer to the Sony HTB600 service manual for disassembly sequence and connector locations.

Technical Specifications

• Board Type: LED Board CG1 SWF
• Compatible Platform: HTB600

Standard Information

• Brand: SONY
• Manufacturer Part Number: 9-301-025-91
