Soler & Palau TRE300 TRe300 Total Recovery Premium Energy Recovery Ventilator 280 CFM 120V/1Ph

Product Description

The SOLER & PALAU TRE300 Total Recovery Premium Energy Recovery Ventilator is an advanced unit designed for residential and light commercial applications. This ERV features an efficient EC motor and can be mounted in any orientation. It allows for individual airstream balancing to account for varying duct run lengths, ensuring optimal indoor air quality by replacing stale air with fresh outdoor air. The unit offers airflow performance from 36 to 288 CFM.

• Efficient EC motor for reduced energy consumption.
• Individual airstream balancing capability for varied duct lengths.
• Flexible installation, suitable for mounting in any orientation.

Product Highlights

The SOLER & PALAU TRE300 is an energy-efficient ERV with an EC motor, offering flexible mounting and individual airstream balancing for residential and light commercial use.

Product Information

Standard Information

• Brand: SOLER & PALAU
• Manufacturer Part Number: TRE300
• Country of Origin: USA

Technical Specifications

• Certifications: HVI Certified, cETLus Listed, Ecowatt®
• Airflow Range: 36-288 CFM
• Minimum Airflow: 30 CFM
• Maximum Airflow: 288 CFM
• External Static Pressure Range: 0.1-1.8 inches w.g.
• Temperature Efficiency Range: 71-86%
• Total Efficiency Winter Range: 63-83%
• Total Efficiency Summer Range: 45-69%
• Mounting Type: Suspended, Wall
• Number of Speeds: Variable
• Port Location: Side
• Type: ERV-Air Supply Fan
• Application: Residential, Light Commercial
• Controls: Electronic
• Maximum Amperage: 1.22 Amps
• Power Supply: Electric
• Voltage: 120V/1Ph
• Power Consumption: 85W
• Wiring Style: Plug
• Duct Diameter: 6.0 in.
