Soler & Palau STXB08RHULPH1S Upblast Exhaust Fan 1/3Hp 1Ph 2100Rpm

Product Description

The SOLER & PALAU STXB08RHULPH1S is an upblast, centrifugal roof-mounted exhaust fan with a belt drive motor. This model is UL762 certified for grease applications. It features an aluminum exterior and a non-overloading backward inclined wheel, making it suitable for restaurant hoods, kitchen exhaust ventilation, and fume and smoke removal.

• Attractive spun aluminum exterior.
• Belt drives permit easy performance adjustments when needed.
• Curved non-overloading backward inclined wheel for efficiency at higher static pressures.

Product Highlights

This exhaust fan is designed for high static pressure applications and is ideal for removing contaminated or high-temperature air.

Product Information

Standard Information

• Brand: SOLER & PALAU
• Manufacturer Part Number: STXB08RHULPH1S
• Country of Origin: United States

Technical Specifications

• Item [Specifications]: Upblast Exhaust Fan,1/3HP,1Ph,2100rpm
• Country of Origin (subject to change) [Specifications]: United States
• Blade Diameter: 8"
• Blade Material: Aluminum
• CFM: 1128
• Drive Type: Belt
• Harmonized System Code: 841459
• Hertz: 60
• Horsepower: 0.33
• Made in the USA: Yes
• Phase: 1 Phase
• RPM: 1128
• Speed: 1 Speed
• Voltage: 110-120V
• Product Type: Restaurant Exhauster
• Installation: Roof or Sidewall
• Exhaust Type: Upblast
• Type of Drive: Belt Drive
• Wheel Size (in.): 8
• Max. BHP: 0.33
• RPMs: 2100
• Max. Static Pressure WG (in.): 1
• Sones Level: 15.0 @ 1/4 SP
• CFM @ Zero Static Pressure: 1128
• Roof Opening (in.): 13.5
• Width (in.): 28.625
• Depth (in.): 28.625
• Height (in.): 29.333
• Net Weight (lbs.): 123
• Certifications: AMCA Air and Sound Licensed, UL 762 Listed
