Soler & Palau STXB08RHULML1S Upblast Centrifugal Roof Exhaust 8 inch 833 CFM Belt Drive

Product Description

The SOLER & PALAU STXB08RHULML1S belt drive fan is designed to exhaust air in high static pressure applications up to 3". Its aluminum exterior provides an attractive appearance. It is ideally suited for the removal of dirty, contaminated, and/or high-temperature air from processes and buildings.

• Temperature rating up to 300 degrees F
• Belt drives permit easy performance adjustments when needed
• Roof or sidewall mounting options

Product Highlights

This centrifugal exhaust fan is suitable for restaurant hoods, kitchen exhaust ventilation, fume and smoke removal, and laboratory fume hood exhaust.

Product Information

Standard Information

• Brand: SOLER & PALAU
• Manufacturer Part Number: STXB08RHULML1S
• Country of Origin: USA

Technical Specifications

• Item #: STXB08RHULML1S
• Blade Diameter: 8"
• Blade Material: Aluminum
• CFM: 833
• Country of Origin: USA
• Drive Type: Belt
• Harmonized System Code: 841459
• Hertz: 60
• Horsepower: 0.25
• Made in the USA: Yes
• Phase: 1 Phase
• RPM: 833
• Speed: 1 Speed
• Voltage: 120
• Product Type: Restaurant Exhauster
• Installation: Roof or Sidewall
• Exhaust Type: Upblast
• Wheel Size (in.): 8
• Max. BHP: 0.13
• RPMs: 1550
• Max. Static Pressure WG (in.): 1/2
• Sones Level: 9.0 @ 1/4 SP
• CFM @ Zero Static Pressure: 833
• Roof Opening (in.): 13.5
• Width (in.): 28.625
• Depth (in.): 28.625
• Height (in.): 29.333
• Net Weight (lbs.): 123
• Certifications: AMCA Air and Sound Licensed, UL 762 Listed
• Application: Restaurant & Gen. Applic.
• CFM Range: 833 - 3,975
• Mount: Wall, Roof
