White-Rodgers 124-114111 DC Power Solenoid 24 Coil Voltage DC 100/50 Amps Continuous Duty

Product Description

The White-Rodgers 124-114111 DC Power Solenoid operates at 24 volts with a coil designed for direct current. This component is rated for 100/50 amps and is suitable for continuous duty applications.

• Continuous duty operation
• Contact form SPNO (Single Pole Normally Open)
• Durable construction for long-lasting performance

Product Highlights

This solenoid is ideal for industrial automation, HVAC systems, and other applications requiring reliable electrical control.

Product Information

Standard Information

• Brand: White-Rodgers
• MPN: 124-114111

Technical Specifications

• Coil Voltage: 24 VDC
• Contact Rating: 100 Amps
• Duty Cycle: Continuous
• Coil Type: Isolated
• Contact Form: SPNO
• Coil Termination: #10-32 UNF-2A Thread
• Contact Termination: 5/16-24 UNF-2A Thread
• Coil Resistance: 53 ohms
• Temperature Range: -40°F to 149°F
• Mounting Base: Standard Bracket
• Contact Material: Silver Alloy
• Series: 124
