Product Description
The SolaHD SDP06-24-100T is a low power DIN rail series power supply designed to deliver efficiency and reliability. This unit provides a voltage output of 24/28 VDC at 0.6 Amps. The design allows for easy installation and adapts well to various industrial applications.
- Input voltage range: 85-264 VAC and 90-375 VDC
- Includes PowerBoost technology for demanding loads
- Compact footprint suitable for tight spaces
Product Highlights
The SDP06-24-100T power supply is ideal for industrial control, building automation, and process control applications.
Product Information
Standard Information
-
Brand: SolaHD
-
Manufacturer: Sola Electric
Technical Specifications
-
Catalog Number: SDP06-24-100T
-
Width: 3.58 inches
-
Height: 2.95 inches
-
Length: 1.77 inches
-
Input Voltage: 85-264 VAC, 90-375 VDC
-
Output Voltage: 24-28 VDC
-
Amperage: 0.6 Amp
-
Material: Plastic
-
Efficiency: 83%
-
Special Features: Overvoltage protection, short circuit protection, adjustable output
-
Applications: Industrial Control, Process Control, Building Automation
-
GTIN: 00783472151608
-
UPC: 783472151608
