SolaHD SDN10-24-480C 24 VDC Output 10 Amp 240 W Din Rail Power Supply

Product Description

The SolaHD SDN10-24-480C is a din rail power supply with 24 VDC output rated at 10 Amps and delivering a maximum power of 240 Watts. This product is designed for industrial applications where reliability is crucial. It operates effectively in extreme environments, making it suitable for hazardous locations and off-shore applications.

• Wide operating temperature range
• PowerBoost capability for short duration overload
• Extensive LED diagnostics for easy monitoring

Product Highlights

The SDN10-24-480C supports universal input voltage and parallel operation, ensuring ease of integration and robust performance in challenging conditions.

Product Information

Standard Information

• Type: Din Rail Power Supply
• Brand: SolaHD

Technical Specifications

• Catalog Number: SDN10-24-480C
• Voltage Rating: 380 - 400 VAC
• Output Voltage: 24 VDC
• Current Output: 10 A
• Wattage: 240 W
• Environmental Conditions: 90% RH Humidity Range
• Material: Metal Housing
• Width: 2.36 inches
• Height: 4.85 inches
• Length: 4.36 inches
• Efficiency: 91.2%
• Phase: 3
• Application: Provides contact closure for remote monitoring of alarm conditions in SolaHD UPS.
• Special Features: Supports redundant operation with optional SDN Redundancy modules.
• UPC: 783472006564
