SolaHD E050TH SOL E050TH 50VA INDL CNTRL TFMR

Product Description

The SolaHD E050TH is an industrial control transformer with a power rating of fifty volt-amperes. This product features encapsulated copper windings, ensuring protection against moisture and contaminants.

• Suitable for harsh environments
• Includes extra deep terminal barriers
• Compatible with multiple voltage configurations

Product Highlights

The SolaHD transformer is designed for reliability in industrial applications. It features an insulation system rated at one hundred five degrees Celsius, making it suitable for heavy-duty use.

Product Information

Standard Information

• Brand: SolaHD
• Manufacturer: Sola Electric

Technical Specifications

• Catalog Number: E050TH
• Power Rating: 50 VA
• Primary Voltage: 240/415/480 V, 230/400/460 V, 220/380/440 V
• Secondary Voltage: 120/240 V, 115/230 V, 110/220 V
• Frequency Rating: 50/60 Hz
• Temperature Rise: 55 Deg C
• Insulation Class: 105
• Mounting: Mounting Plate
• Phase: 1
• Approval: UL 506, UL (Canada and US), CE, CSA C22.2, JIC
• Terminal Type: Screw
• Size: 3.39 IN x 4.36 IN x 2.96 IN
