White-Rodgers 3F01-160 Snap Disc Fan Control 160F

Product Description

The White-Rodgers 3F01-160 Snap Disc Fan Control is a reliable component for precise temperature monitoring in HVAC systems. It activates at 160 degrees Fahrenheit to ensure efficient temperature management. Ideal for use in industrial and commercial settings.

• Automatic reset for hassle-free operation
• Quick-connect electrical connections for easy installation
• Compact design for versatile applications

Product Highlights

This fan control by White-Rodgers offers dependable temperature regulation. It features a snap-disc mechanism that ensures activation at 160 degrees Fahrenheit. The device is compact and easy to install, making it suitable for a variety of HVAC applications.

Product Information

Standard Information

• Brand: White-Rodgers
• Manufacturer: Emerson Electric
• Part #: 3F01-160
• UPC: 786710001741

Technical Specifications

• Type: Automatic Reset
• Series: 3F01
• Dimensions: 1.23 in L x 1.32 in W x 0.37 in H
• Contact Form: SPST
• Differential: 20 deg F
• Mounting Type: Airstream
• Switch Action: Close on Rise
• Inductive Rating: 5.8/34.8 A at 120 VAC, 2.9/17.4 A at 240 VAC
• Resistive Rating: 25 A at 120/240 VAC
• Pilot Duty Rating: 125 VA
• Temperature Rating: 150 deg F Cut-In/130 deg F Cut-Out
• Electrical Connections: Quick-Connect
