Smith-Blair 411-00028810-003 Coupling 300 PSI 2-1/2 x 2-1/2 Sleeve

Product Description

The Smith-Blair 411-00028810-003 is a straight coupling designed for joining plain end pipes with a size of two and a half inches. This coupling is fabricated from carbon steel and features a Flexi-Coat fusion bonded epoxy coating for durability and resistance to corrosion.

• Pressure rating of 300 PSI
• Temperature range from negative twenty to one hundred eighty degrees Fahrenheit
• Includes high strength bolts for secure installation

Product Highlights

This coupling allows for easy installation without the need for welding or special fittings.

Product Information

Standard Information

• Manufacturer: Smith-Blair
• Type: Straight

Technical Specifications

• Overall Length: fifteen inches
• Pipe Outer Diameter: two point eight eight inches
• Sleeve Size: twelve inches length x zero point two zero three inches thickness
• Flange Outer Diameter: six and one half inches
• Bolt Size: three five eighths inch diameter x fifteen inches length
• Material: ASTM A513/A53
• Pressure Rating: 300 PSI
• Temperature Rating: negative twenty to one hundred eighty degrees Fahrenheit
