Smith-Blair 411-00028801-003 2-1/2 x 2-1/2 Coupling 300 PSI

Product Description

The Smith-Blair 411-00028801-003 is a bolted steel coupling designed to join plain end pipes of the same diameter effectively. This coupling measures two and one-half inches by five inches, featuring a pressure rating of three hundred PSI. It is manufactured with carbon steel and coated with Flexi-Coat fusion bonded epoxy for durability and rust resistance.

• Designed for easy installation without special preparations
• Suitable for a variety of piping materials including carbon steel and PVC
• Angular deflection of four degrees allows for flexibility in piping direction

Product Highlights

Ideal for applications where welding is impractical. Allows limited expansion and contraction during temperature variations. This coupling is effective for dampening vibrations, thus reducing pipe fatigue.

Product Information

Standard Information

• Manufacturer: Smith-Blair
• Material: Carbon Steel

Technical Specifications

• Overall Length: 8 inches
• Pressure Rating: 300 PSI
• Temperature Range: -20 to 180 degrees F
• Pipe Outer Diameter: 2.88 inches
• Sleeve Size: 5 inches length x 0.203 inches thickness
• Flange Outer Diameter: 6.5 inches
• Bolt Size: (3) 5/8 inches diameter x 8 inches length
• Applicable Standards: UL, NSF/ANSI 61/372, AWWA C219/C213
