SMC KQG2L10-03S KQG2 Pneumatic Elbow 10 mm x R3/8

Product Description

SMC KQG2L10-03S is a pneumatic elbow fitting designed for various piping applications. This fitting is made from high-quality stainless steel to ensure durability. The nominal size is 10 millimeters and R3/8. It is suitable for handling pressures from -100 KPa to 1 MPa and can operate in temperatures ranging from -5 to 150 degrees Celsius. This fitting is ideal for pneumatic systems that require reliable connections.

• Material: Stainless Steel 316
• Pressure Rating: -100 KPa to 1 MPa
• Temperature Range: -5 to 150 degrees Celsius

Product Highlights

The KQG2L10-03S fitting features a one-touch design for simple installation and removal. It is compatible with various tubing materials, including FEP and polyurethane. This fitting is not intended for use in potable water systems.

Product Information

Standard Information

• Brand: SMC
• MPN: KQG2L10-03S

Technical Specifications

• Series: KQG2
• Hex Size: 17 mm
• Length: 21 mm
• Nominal Size: 10 mm x R3/8
• Fitting/Connector Type: Elbow
• Country of Origin: JP
