SMC KQ2L10-U04A One Touch Fitting with 10 mm x Uni 1/2 Nominal

Product Description

The SMC KQ2L10-U04A is a male one touch fitting designed for various pneumatic applications. It features a fitting/connector type of 90-degree elbow. This fitting is suitable for a nominal size of ten millimeters by universal one-half inch, designed to connect female push-in tube with a one-half male universal threaded end.

• Operating pressure range from -100 kPa to 1 MPa
• Temperature rating from -5 to 60 degrees Celsius
• Constructed from brass, ideal for various fluid types

Product Highlights

This product is engineered to accept various tube types including FEP, PFA, nylon, and polyurethane. The release collar allows for easy disconnection without damaging the tubing.

Product Information

Standard Information

• Brand: SMC
• MPN: KQ2L10-U04A

Technical Specifications

• Series: KQ2
• Length: 31.5 mm
• Hex Size: 22 mm
• Material: Brass
• Pressure Rating: -100 kPa to 1 MPa
• Nominal Size: 10 mm x Uni 1/2
• Color: Gray/White
• Country of Origin: JP
