SMC KQ2H06-08A KQ2 Oval Male Connector 6 x 8 mm

Product Description

SMC, KQ2H06-08A, is an oval male connector designed for various pneumatic applications. This fitting connects to tubes with a nominal size of six millimeters by eight millimeters. It operates efficiently in a pressure range from negative one hundred kilopascals to one megapascal. The construction is brass, ensuring durability and compatibility with several materials.

• Connects 6 mm x 8 mm tubes.
• Pressure range: -100 kPa to 1 MPa.
• Release collar for easy tubing removal.

Product Highlights

This connector is suitable for various tube materials including FEP, PFA, nylon, and polyurethane. It is ideal for air and water applications, with temperature ratings suitable for both.

Product Information

Standard Information

• Brand: SMC
• MPN: KQ2H06-08A

Technical Specifications

• Nominal Size: 6 x 8 mm
• Length: 28.5 mm
• Material: Brass
• Pressure Rating: -100 kPa to 1 MPa
• Temperature Rating: -5 to 60 °C (air), 0 to 40 °C (water)
• End Style: Tube
• Fitting Type: Connector
• Country of Origin: JP
