SMART ELECTRIC SE8888 PKRD 49101 1/12, 1/15, 1/20 REF MTR REV CW CCW 115/208-230v 1550

Product Description

The SMART ELECTRIC SE8888 is a shaded pole motor with a range of power ratings including one twelfth, one fifteenth, and one twentieth horsepower. This motor operates at a voltage between one hundred fifteen and two hundred thirty volts AC and is suitable for both clockwise and counterclockwise rotation. The motor's speed is rated at fifteen hundred fifty RPM.

• Power Rating: 1/12 HP, 1/15 HP, 1/20 HP
• Voltage Rating: 115/208 to 230 Volt AC
• Reversible Operation: Yes

Product Highlights

This motor is designed for various applications where reversible motion is required. It operates efficiently at a frequency of fifty to sixty hertz. The motor has a full load amp rating of one point one to zero point five amps.

Product Information

Standard Information

• Approvals: UL (Canada and US)
• Insulation Class: B

Technical Specifications

• Number of Speeds: 1
• Operating Temperature Rating: 32 to 104 Deg F
• Capacitance: 4 Microfarad
• Bearing Type: Ball
• Diameter: 3.3 Inch
• Weight: 3.84 Pound
