Sloan 3346097 Esd800a Cp Soap Dispenser Battery (2 x 1500 ml / 36°) ESD-321

Brand: SLOAN
SKU: 3346097
Availability: In Stock

Ships same day if ordered by 12 pm

$366.14
$366.14
HAVE A QUESTION?

Our team is ready to help!

  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Product Description

The Sloan 3346097 is an Esd800a sensor-activated electronic foam soap dispenser designed for deck-mounted hand washing. The unit features a chrome-plated die-cast body, sealed spout electronics, and a suspended under-counter motor assembly that rotates 36 degrees for installation. It is battery powered with an estimated 45,000 activations, ships with two 1500 ml non-scented foam soap bottles, and dispenses roughly 1,500 times per bottle.

  • Sensor-activated, touch-free foam dispensing with sealed electronics in the spout
  • Battery powered with approximately 45,000 activations; includes battery pack (four D alkaline cells) and two 1500 ml foam soap bottles (~1,500 dispenses each)
  • Deck-mounted modular one-piece construction; motor assembly suspended under counter and rotates 36 degrees for installation

Product Highlights

Deck-mounted sensor foam dispenser; battery operation (~45,000 activations); two 1500 ml soap bottles included; sealed spout electronics; 36° rotatable under-counter motor assembly.

Product Information

Standard Information

  • Brand: SLOAN
  • Manufacturer Part Number: 3346097
  • Country of Origin: United States
Technical Specifications
Brand
Sloan
MPN
3346097
Model
ESD-800 / ESD800A
Product Type
Foam soap dispenser
Mounting Type
Deck-mounted
Maximum Deck Thickness
2 inches
Operation
Sensor activated (touch-free)
Sensor Type
Infrared (IR)
Dispenser Type
Foam, drip-free
Power Type
Battery
Battery
Battery pack included (4 D alkaline cells)
Battery Life
Approximately 45,000 activations
Soap Included
Two non-scented, non-colored foam soap bottles
Soap Bottle Volume
1500 ml per bottle
Dispenses per Bottle
Approximately 1,500 dispenses
Motor Assembly
Suspended under counter, connected to spout
Motor Rotation
36 degrees
Electronics
All electronics sealed within spout
Sensor Range
Nominal 5 inches
Dimensions (L x W x H)
12 x 11.375 x 3.5 inches
Height
3.5 inches
Weight
13.5 lbs
Material
Die cast body
Finish
Polished chrome
ADA Compliant
Yes
Optional Accessories
AC adapter (part 0346090 / ESD-324) for hardwiring
Included Components
Soap bottles (2 x 1500 ml), battery pack (4 D cells), mounting hardware
