SKF BA8 Ball Thrust Bearing - Single-Direction, 8 mm Bore, 19 mm OD, 7 mm Width

Product Description

The SKF BA8 is a single-direction ball thrust bearing with a bore diameter of eight millimeters and an outside diameter of nineteen millimeters. This bearing is designed for applications requiring the support of axial loads. It features a robust construction that ensures long-term reliability and efficiency in operation.

• Single-direction thrust bearing
• Bore diameter of eight millimeters
• Outside diameter of nineteen millimeters

Product Highlights

This product is commonly used in various industrial applications where axial support is critical. The SKF BA8 is well-suited for environments requiring durable and reliable performance.

Product Information

Standard Information

• Brand: SKF
• Part Number: 101175880

Technical Specifications

• Bore Diameter: 8 mm
• Outside Diameter: 19 mm
• Overall Width: 7 mm
• Max RPM: 17000 rpm
• Fillet Radius: 0.3 mm
• Radial Dynamic Load Capacity: 3.19 kN
• Thrust Bearing Type: Single-Direction
