SKF 7334BCBM Single Row Angular Contact Ball Bearing, 40 deg, 170 mm Bore x 360 mm OD x 72 mm W, Machined Brass

Product Description

SKF 7334BCBM is a single row angular contact ball bearing. It is designed to accommodate axial loads in one direction. This type of bearing is commonly adjusted against a second bearing for improved performance. The non-separable design includes one high and one low shoulder, allowing for a high number of balls within the bearing. This structure contributes to a higher load-carrying capacity.

• Single row design allows for unidirectional axial load support
• Includes machined brass cage for enhanced durability
• Operating speed rating of up to 2200 RPM with grease

Product Highlights

The SKF 7334BCBM bearing is suitable for high-speed applications that require precision load-bearing solutions.

Product Information

Standard Information

• Brand: SKF BEARINGS
• Part Number: 7334BCBM

Technical Specifications

• Bore Diameter: 170 mm
• Outside Diameter: 360 mm
• Width: 72 mm
• Cage Material: Machined Brass
• Static Load Capacity: 110156.3 lbf
• Dynamic Load Capacity: 87675.4 lbf
• Speed Rating: 2200 RPM (grease), 2000 RPM (oil)
