SKF 7310BECBM Single Row Cylindrical Bore Angular Contact Ball Bearing 40 Deg (50 mm Bore x 110 mm OD x 27 mm W)

Product Description

The SKF 7310BECBM is a single row cylindrical bore angular contact ball bearing. It features a bore size of fifty millimeters and an outer diameter of one hundred ten millimeters. This bearing type is designed to accommodate axial loads in one direction and is typically paired with another bearing for optimal support.

• Manufactured from bearing steel material.
• Description: 1.97 inches inner diameter, 4.33 inches outer diameter, and 1.06 inches width.
• Contact angle of forty degrees enhances load distribution.

Product Highlights

This bearing provides high load capacity due to its unique design and the ability to house more rolling elements. It is ideal for applications where axial loads in one direction need to be managed.

Product Information

Standard Information

• Brand: SKF
• MPN: 7310BECBM

Technical Specifications

• Bore Diameter: 50 mm
• Outer Diameter: 110 mm
• Width: 27 mm
• Cage Material: Machined brass
• Contact Angle: 40 degrees
• Bearing Type: Unmounted, angular contact
• Dynamic Load Capacity: 16860.6 lbf
• Static Load Capacity: 11465.2 lbf
