SKF 6338 M Single Row Deep Groove Radial Ball Bearing 190 mm Bore x 400 mm OD x 78 mm W

Product Description

The SKF 6338 M is a single row deep groove radial ball bearing, designed with a bore of one hundred ninety millimeters and an outer diameter of four hundred millimeters. The width of this bearing is seventy-eight millimeters. This type of bearing features deep, uninterrupted raceway grooves that allow it to handle both radial and axial loads in both directions.

• Single row design for versatility.
• Available with or without seals.
• Accommodates high-speed operations.

Product Highlights

This bearing is suitable for use in various applications, including fans and pumps, where reliability and performance are crucial.

Product Information

Standard Information

• Brand: SKF BEARINGS
• Part Number: 6338M/C3

Technical Specifications

• Bore Diameter: 190 mm
• Outside Diameter: 400 mm
• Width: 78 mm
• Cage Material: Machined Brass
• Number of Rows: 1
• Dynamic Load Capacity: 371000 N
• Static Load Capacity: 430000 N
• Temperature Rating: -40 to 100 °C
