Sje-rhombus 1006043 Float Switch Normally Open 15 Ft Cord

Product Description

The SJE-RHOMBUS 1006043 is a SignalMaster narrow angle float switch in a normally open configuration, designed to monitor high liquid levels in pump control and alarm systems. When the float tips slightly above horizontal, the snap-action contact closes, signaling a high level condition. When the float drops slightly below horizontal, the contact opens. Mechanically activated and built with a high-impact, corrosion-resistant polypropylene float housing, this switch is suited for continuous use in wet, chemically active environments. It ships with a 15-foot cord and features a yellow cap for quick field identification as a normally open unit.

This float switch is used in residential and commercial water and sewage applications, including sump basins, lift stations, and pump control panels. It mounts in a fixed position and is not sensitive to rotation, allowing flexible installation in tight or oddly oriented wet wells. Licensed plumbers and pump service technicians are the primary installers. The narrow angle activation range makes it well suited for applications requiring a precise trigger point relative to liquid level.

Key Features

• Normally open configuration closes contact when float tips above horizontal, indicating high level
• Mechanically activated snap-action contacts for reliable, repeatable switching
• High-impact, corrosion-resistant polypropylene float housing for use in sewage and water environments
• Control differential of 1.5 inches above or below horizontal for precise level detection
• Yellow cap provides instant visual identification as a normally open switch in the field
• Not sensitive to rotation, simplifying installation orientation

Compatibility

Designed for use with pump control panels and alarm systems in water and sewage liquid level monitoring applications.

Installation Notes

Installation is typically performed by a licensed plumber or pump systems technician. Power to the control panel and pump circuit must be shut off before making any wiring connections. The cord should be secured and routed to prevent abrasion or submersion beyond its rated length. Follow all applicable local plumbing and electrical codes when integrating this switch into a pump control or alarm circuit.

Technical Specifications

• Configuration: Normally Open
• Activation Angle: Narrow Angle
• Control Differential: 1.5 inches above or below horizontal
• Cord Length: 15 feet
• Float Housing Material: High-impact polypropylene
• Contact Type: Mechanically activated snap-action
• Identification Cap Color: Yellow

Standard Information

• Brand: SJE-RHOMBUS
• Manufacturer Part Number: 1006043
