Sioux Chief sc-630wg248 Stub-out Elbow 1/2 in F1960 Pex

Product Description

The SIOUX CHIEF sc-630wg248 is a no-lead stub-out elbow designed for F1960 PEX distribution systems in residential and light commercial plumbing installations. The elbow measures 4 inches by 8 inches and accepts a 1/2 inch F1960 connection, making it compatible with sweat, push-fitting, and compression-style valves at the fixture end. This fitting bridges PEX rough-in work with standard copper stub-out terminations, giving installers flexibility at the wall connection point. Licensed plumbers use this elbow during new construction and remodel work where a solid, bracket-mounted stub-out is required.

This fitting is suited for residential and commercial water distribution rough-in work where F1960 PEX is the primary pipe material. The Square O Straps included with the fitting affix to the SIOUX CHIEF Edge bracket or any standard backing board, allowing the stub-out to be secured to framing during rough-in before drywall is installed. Multiple mounting hole positions support installation on the side, bottom, or top of backing boards, accommodating a variety of framing orientations and fixture heights.

Key Features

• Accepts sweat, push-fitting, and compression valves at the outlet end
• F1960 PEX connection for use with expansion-style PEX systems
• No-lead construction meets safe drinking water requirements
• Square O Straps secure to Edge bracket or any backing board
• Multiple mounting hole positions allow side, bottom, or top installation
• Combines copper stub-out adaptability with F1960 PEX system compatibility

Compatibility

Designed as an OEM-style replacement and new-installation fitting for F1960 expansion PEX plumbing systems requiring a stub-out elbow with multi-valve compatibility at the outlet.

Installation Notes

Installation is performed by a licensed plumber. Shut off the water supply and depressurize the line before making any connections. Secure the Square O Strap to a backing board or Edge bracket before pressure-testing the system. Follow applicable IPC and local plumbing code requirements for support spacing and no-lead fixture fittings.

Technical Specifications

• Connection Type (PEX End): 1/2 inch F1960 expansion PEX
• Stub-Out Dimensions: 4 inches x 8 inches
• Lead Content: No-lead
• Compatible Valve Types: Sweat, push-fitting, compression
• Mounting: Square O Strap, side/bottom/top mounting hole positions

Standard Information

• Brand: SIOUX CHIEF
• Manufacturer Part Number: sc-630wg248
