Sioux Chief 696-12A TurboVent 2 in. 160 Dfu Abs air vent (2 in.)

Product Description

Sioux Chief 696-12A is a TurboVent 2-inch ABS air admittance valve rated 160 DFU designed to provide venting for residential drain, waste, and vent systems. The unit uses an internal actuating device that spins on activation to keep the elastomeric seal free of debris and ships with a protective debris cover and sleeve for construction. Kit includes a 2-inch Schedule 40 hub adapter and OxBox access box for installation and maintenance.

• 2 in. ABS body with internal actuating device that spins on activation to clear the sealing surface
• Rated 160 DFU; positive seal at 0 PSI and withstands up to 13 psi back-pressure
• Includes 2 in. Schedule 40 hub adapter, OxBox access box, and protective debris cover

Product Highlights

2 in. TurboVent AAV kit with OxBox and 2 in. hub adapter; 160 DFU rating; 13 psi positive seal; ASSE 1050/1051 certified.

Product Information

Standard Information

• Brand: SIOUX CHIEF
• Manufacturer Part Number: 696-12A
• Country of Origin: United States

Technical Specifications

• Brand: Sioux Chief
• MPN: 696-12A
• Product type: TurboVent air admittance valve kit with OxBox access box
• Model/Series: 696
• Body Material: ABS
• Softgoods Material: Elastomer
• Nominal Size: 2 in
• DFU Rating: 160 DFU
• Pressure Rating: 13 psi
• End Style: Thread x Hub
• Connection Type: Schedule 40 hub adapter (thread x hub)
• Includes: OxBox access box; 2 in. hub adapter; protective debris cover
• Standards/Certifications: ASSE 1050; ASSE 1051; ASTM D2661; ASTM D2665; ASTM F409; NSF/ANSI 14; IAPMO
• UPC: 739236100689
• Dimensions: 2.6875 in W x 2.125 in H
• Weight: 0.775 lbs
• Country of Origin: US
• Item Number: SIO69612A
• Unit of Measure: EA
