Sioux Chief 648-CG7FP 648 Series 2 Inch Brass Full Port Solvent Weld 600# Ball Valve

Product Description

The Sioux Chief 648-CG7FP is a two-inch brass full port ball valve designed for solvent weld applications. This valve features a CPVC connection with a maximum pressure rating of six hundred psi. It is suitable for handling various media including water, oil, and gas. The valve is crafted for durability and efficiency in plumbing systems.

• CPVC Socket x CPVC Socket connection
• Blow-out proof stem
• Full port design allows for maximum flow

Product Highlights

This ball valve is reliable and easy to operate with a quarter turn lever. It is compliant with industry standards and is designed for lead-free applications.

Product Information

Standard Information

• Brand: Sioux Chief
• MPN: 648-CG7FP

Technical Specifications

• Nominal Size: 2 inches
• Body Material: Brass
• Ball Material: Chrome Plated
• Seal Material: EPDM
• Seat Material: PTFE
• Maximum Pressure Rating: 600 psi WOG
• End Style: CPVC
• Series: 648
