Sioux Chief 633X02 Fitting 2-1/2 PEX 3/4 FIP Swivel Conn (2 in)

Product Description

Sioux Chief 633X02 is a PEX-to-FIP swivel fitting that connects 2-1/2 PEX tubing to a 3/4-inch female iron pipe swivel for water heater and PowerPex system applications. The Type L copper, 2 in length fitting features a brass FIP swivel nut with an EPDM gasket, a lead-free solder joint and a full-flow dielectric design compliant with ASTM F1807 and related standards.

• Connects 2-1/2 PEX to 3/4 in female iron pipe (FIP) swivel for water heater and PowerPex system use
• Type L copper construction, 2 in length, brass FIP swivel nut with EPDM gasket; do not use thread sealant on swivel threads
• Full-flow dielectric design, lead-free solder joint, NL/DZR construction; complies with ASTM F1807, CSA B137.5, NSF/ANSI 14, NSF/ANSI/CAN 372 and NSF/ANSI/CAN 61

Product Highlights

Type L copper, 2 in PEX-to-FIP swivel fitting with brass FIP nut and EPDM gasket; full-flow dielectric design and multiple standards compliance.

Product Information

Standard Information

• Brand: SIOUX CHIEF
• Manufacturer Part Number: 633X02
• Country of Origin: US

Technical Specifications

• Brand: Sioux Chief
• MPN: 633X02
• Description: Fitting 1/2 PEX to 3/4 in FIP Swivel Connection, 2 in length
• PEX Size: 1/2 in
• Connection 1 Size: 1/2 in
• Connection 1 Type: PEX (ASTM F1807 compatible)
• Connection 2 Size: 3/4 in
• Connection 2 Type: FIP swivel
• Length: 2 in
• Material: Copper (Type L)
• FIP swivel nut material: Brass
• Gasket Material: EPDM
• Design: Full-flow dielectric
• Lead Free: Yes
• NL/DZR: Yes
• Standards/Certifications: ASTM F1807; CSA B137.5; NSF/ANSI 14; NSF/ANSI/CAN 372; NSF/ANSI/CAN 61
• Weight (lbs): 0.16
• Unit of Measure: EA
• UPC: 739236495433
• GTIN-14: 10739236495430
• Country of Origin: US
• Notes: Do not use thread sealant on FIP swivel threads; lead-free solder joint
