Sioux Chief 130-G1F1C 3/8 FIP x 3/8 compression 1/4-turn angle stop

Product Description

The Sioux Chief 130-G1F1C is a quarter-turn angle stop with a 3/8 FIP inlet and 3/8 compression outlet designed to control pressurized water supply lines to fixtures. It features a brass (bar stock) body with PTFE seat softgoods and a chrome-plated finish, and provides 90 degree orientation for space-saving installation in residential plumbing.

• 3/8 FIP inlet and 3/8 compression outlet for fixture supply connections
• Quarter-turn (1/4-turn) operation with 90 degree angle stop configuration
• Brass bar stock body with PTFE seat and chrome-plated finish; certified to ASME A112.18.1, CSA B125.1, NSF/ANSI/CAN 61, and Safe Drinking Water Act 1417(d)

Product Highlights

Quarter-turn 3/8 FIP x 3/8 compression angle stop; brass body with PTFE seat; chrome-plated finish; intended for residential water supply lines.

Product Information

Standard Information

• Brand: SIOUX CHIEF
• Manufacturer Part Number: 130-G1F1C
• Country of Origin: China

Technical Specifications

• Brand: SIOUX CHIEF
• Manufacturer Part Number: 130-G1F1C
• Item Description: 3/8 FIP x 3/8 Compression NL 1/4-Turn Angle Stop
• Series: 130
• Nominal Size: 3/8 in
• Connection 1 Type: FIP
• Connection 1 Size: 3/8 in
• Connection 2 Type: Compression
• Connection 2 Size: 3/8 in
• End Style: FIP x Compression
• Orientation: Angle (90 degree)
• Operation: Quarter-turn (1/4-turn)
• Body Material: Brass (bar stock brass)
• Softgoods Material: PTFE seat
• Finish: Chrome plated
• Dimensions: 2.402 in L x 0.891 in W x 1.603 in H
• Weight: 0.27916667 lb
• UPC: 739236502261
• Country of Origin: CN
• Certifications: ASME A112.18.1; CSA B125.1; Safe Drinking Water Act 1417(d); NSF/ANSI/CAN 61
