Simpson Strong Tie L70Z L-angle Z-max 7 in 16 Gauge

Product Description

The SIMPSON STRONG TIE L70Z is a 7-inch L-angle connector designed to reinforce 90-degree angle connections in wood framing applications. Formed from 16-gauge Z-Max galvanized steel, it resists corrosion in treated-lumber environments where standard galvanized hardware falls short. The connector ships pre-set at 90 degrees and installs with six 10D HDG nails. A staggered nail pattern reduces the risk of wood splitting during fastening, and the wider leg provides solid bearing surface against joist faces for added load transfer. Carpenters, framers, and general contractors use this connector in both residential and light commercial framing where reliable angle connections are required.

The L70Z is suited for wood-to-wood angle connections in floor framing, deck framing, and structural joist applications. It performs in both interior and exterior settings, including installations involving pressure-treated lumber where the Z-Max coating provides the necessary corrosion resistance. The connector is sold in packages of 50 units, making it practical for framing crews working on repetitive joist and header connections across a full project.

Key Features

• 16-gauge Z-Max galvanized steel construction for corrosion resistance with pressure-treated lumber
• Staggered nail pattern reduces wood splitting during installation
• Wider leg increases nailing surface into joist for improved load transfer
• Ships pre-set at 90 degrees for consistent, repeatable installation
• Stronger connection than conventional toe-nailed joints
• Installs with six 10D HDG nails — no special tooling required

Compatibility

Designed as an OEM-style replacement and standard framing connector for wood-to-wood 90-degree angle connections in residential and light commercial construction.

Installation Notes

Installation is typically performed by framers or carpenters during rough framing or deck construction. Fasten using the specified 10D HDG nails through all provided nail holes to achieve rated load values. Ensure lumber surfaces are flush and square before driving fasteners. Follow applicable building codes and connector manufacturer load tables when specifying this hardware for structural applications.

Technical Specifications

• Length: 7 inches
• Gauge: 16 gauge
• Material: Z-Max galvanized steel
• Fasteners Required: Six 10D HDG nails
• Angle: 90 degrees
• Package Quantity: 50 per package
• Package Weight: 18 pounds

Standard Information

• Brand: SIMPSON STRONG TIE
• Manufacturer Part Number: L70Z
