Simpson Electric M235-0-0-46-0 Ac Ammeter Panel Meter

Product Description

The SIMPSON ELECTRIC M235-0-0-46-0 is a 3-1/2 digit digital LCD panel meter configured as an AC ammeter for electrical panel and control cabinet applications. It accepts input up to 5 amps and 250 VAC across a frequency range of 4 to 440 Hz, making it suitable for both standard 50 Hz and 60 Hz power systems as well as variable-frequency drive applications. The display uses red LCD digits for high-contrast readability in control panel environments. Screw terminals provide a secure, field-wireable connection. Licensed electricians and industrial maintenance technicians are the primary installers of this type of instrument.

This panel meter is used to monitor AC current in residential, commercial, and light industrial electrical panels, motor control centers, generator switchgear, and custom control enclosures. Its wide frequency tolerance of 4 to 440 Hz makes it a practical choice for installations involving variable-frequency drives or non-standard power sources. The compact panel-mount form factor is designed to drop into a standard cutout and secure from the front.

Key Features

• 3-1/2 digit digital LCD display with red digit color for clear panel readability
• Measures AC current up to 5 amps
• Accepts input voltage up to 250 VAC
• Wide frequency range of 4 to 440 Hz supports VFD and non-standard power applications
• Screw terminal connections for reliable field wiring
• Panel-mount design for integration into control cabinets and switchgear

Compatibility

Designed as an OEM-style panel meter for use in electrical control panels, motor control centers, and switchgear enclosures requiring AC current measurement up to 5 amps at 250 VAC.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements. De-energize the panel and verify zero voltage with a meter before wiring. Use the screw terminals to connect the current input leads securely and torque terminals to the enclosure manufacturer's specification. Ensure the panel cutout dimensions match the meter's mounting requirements before installation.
