Signify RC2S102TPI Electromagnetic Fluorescent Ballast 102 W 120 VAC

Product Description

Signify RC2S102TPI is an electromagnetic fluorescent ballast designed for T12 lamps. It operates at 120 VAC and supports lamp wattage up to 102 watts. This ballast is used in various applications including libraries, reception areas, and schools.

• Compatible with T12 lamps
• Ballast factor of 0.87
• Measures fourteen point thirty-one inches by three point nineteen inches by two point sixty-three inches

Product Highlights

This ballast features rapid start capabilities, a high power factor, and thermal protection.

Product Information

Standard Information

• Manufacturer: Signify
• MPN: RC2S102TPI

Technical Specifications

• Amperage Rating: 2.1 A
• Application: TV, Radio Station, Library, Reception, Reading Room, Church and School Study Hall Applications
• Ballast Factor: 0.87
• Ballast Grade: ANSI C82.1
• Dimensions: 14.31 in L x 3.19 in W x 2.63 in H
• Frequency Rating: 60 Hz
• Lamp Type: T12
• Lamp Wattage: 102 W
• Material: Metal
• Minimum Starting Temperature: -20 deg F
• Number of Lamps: 2
• Power Factor: 0.87
• Series: Standard
• Standards/Approvals: RoHS Compliant | UL File No. E14927 | CSA File No. 007310 | ANSI C82.1
• Start Type: Rapid
• Thermal Protection: Class P
• Total Harmonic Distortion: 30 %
• Voltage Rating: 120 VAC
