Signify ICN2TTP40SC35I Advance Centium Electronic Compact Fluorescent Ballast 40 W

Product Description

The SIGNIFY ICN2TTP40SC35I Advance Centium electronic ballast is designed for compact fluorescent (CFL) lamps, operating at 120 to 277 VAC and supporting 40 W lamps. This ballast features lamp striation reduction technology, making it compatible with energy-saving T8 lamps. It is an optimal choice for new construction and retrofit applications within the commercial sector.

• Reliable and robust design
• Compatible with energy saving T8 lamps
• Optimal choice for new construction and retrofit applications

Product Highlights

Ideal for general office lighting, conference rooms, decorative lighting, and new fixture designs requiring smaller ballasts.

Product Information

Standard Information

• Brand: SIGNIFY
• Manufacturer Part Number: ICN2TTP40SC35I
• Country of Origin: US - United States

Technical Specifications

• Lamp Type: CFL
• Lamp Wattage: 40 W
• Voltage: 120 to 277 VAC
• Starting Method: Instant
• Ballast Factor: 0.88
• Wattage: 68/67 W
• Current: 0.25 to 0.57 A
• Frequency: 60 Hz
• Minimum Starting Temperature: 0 deg F
• Total Harmonic Distortion: 10 %
• Power Factor: 0.98
• Number of Lamps: 2 Lamps
• Lamp Base: 4-Pin 2G11 Lamp Base
• Maximum Case Temperature: 70 deg C
• Application: Retail, Commercial, Institutional and Industrial, School, Office, Specialty and Department Stores, Warehouses and Manufacturing Applications
• Dimensions: 9.5 in L x 1.7 in W x 1.18 in H
• Manufacturer Part Number: ICN2TTP40SC35I
• Standards/Approvals: RoHS Compliant|UL File No. E14927|CSA File No. 007310
• Type: Electronic
• Voltage Rating: 120 to 277 VAC
• Ballast Input Voltage: 120/277 V
• Ballast Technology: Electronic
• Lamp Watts: 40W
• Input Wattage: 68-67 W
• Wire Size: 18 AWG
• Wire Type: Solid
• Housing Material: Metal
