Signify ICN2S86SC35I Advance Centium Electronic Fluorescent Ballast 86 W

Product Description

The SIGNIFY ICN2S86SC35I Advance Centium electronic fluorescent ballast is designed for T8/HO lamps. It supports 86 W lamps and operates on 120 to 277 VAC. This ballast features a programmed start and a ballast factor of 1. It is suitable for use with 2 lamps.

• Small can design
• Electronic fluorescent ballast
• Supports T8/HO lamps

Product Highlights

This electronic ballast is designed for T8/HO lamps, operates on 120 to 277 VAC, and features a programmed start.

Product Information

Standard Information

• Brand: SIGNIFY
• Manufacturer Part Number: ICN2S86SC35I
• Country of Origin: USA

Technical Specifications

• Lamp Type: T8/HO
• Wattage: 86 W
• Voltage: 120 to 277 VAC
• Ballast Type: Electronic
• Ballast Factor: 1
• Current: 0.65 to 1.52 A
• Frequency: 50/60 Hz
• Start Type: Programmed Start
• Total Harmonic Distortion: 0.1
• Power Factor: 0.99
• Number of Lamps: 2 Lamps
• Temperature: 70 deg C
• Material: Metal
• Dimensions: 9.5 in L x 1.7 in W x 1.18 in H
• Amperage Rating: 0.65 to 1.52 A
• Frequency Rating: 50/60 Hz
• Lamp Wattage: 86 W
• Manufacturer Part Number: ICN2S86SC35I
• Standards/Approvals: UL Listed|CSA Certified
• Type: Small Can
• Voltage Rating: 120 to 277 VAC
• Standard: CSA certificate;UL certificate;CEC Listing;Circle E logo;DOE;RoHS Compliant
• UPC: 781087138458
• GTIN: 00781087138458
