Signify ICN2S5490CN35M ADV ICN2S5490CN35M ELE MH BAL 70W M

Product Description

The Advance ICN2S5490CN35M is an electronic fluorescent ballast from Signify. This ballast operates efficiently across a range of line voltages from 120 to 480 volts. It is suitable for various applications, particularly in environments with higher ambient temperatures where a rating of 90 degrees Celsius is required. This product is designed for use with T5HO lamps, providing reliable performance and energy efficiency.

• IntelliVolt operation between 120 to 277 volts
• Suitable for outdoor applications
• High power factor for energy savings

Product Highlights

This product supports programmed start technology, ensuring a stable kickstart for your fluorescent lamps. The construction ensures durability and longevity, making it a reliable choice for commercial settings.

Product Information

Standard Information

• Brand: Signify
• Manufacturer Part Number: ICN2S5490CN35M

Technical Specifications

• Amperage Rating: 0.43 to 1 A
• Application: Outdoor Applications
• Ballast Factor: 1
• Dimensions: 9.5 in L x 1.3 in W x 1 in H
• Frequency Rating: 50/60 Hz
• Lamp Type: T5HO
• Lamp Wattage: 54 W
• Material: Metal
• Number of Lamps: 2
• Power Factor: 0.98
• Standards/Approvals: CSA Certified, UL Listed
• Start Type: Programmed
• Temperature Range: 90 degrees C
• Total Harmonic Distortion: 10%
• Voltage Rating: 120 to 277 VAC
• Weight: 1.008 lb
