Signamax Inc. 48U-HDMMP-A 48-port Angled Patch Panel

Product Description

The SIGNAMAX INC. 48U-HDMMP-A is a 48-port field-configurable angled patch panel designed for structured cabling installations in telecommunications rooms and data centers. It accepts field-termination inserts, allowing technicians to configure the panel for the specific connector types required by the job. The angled faceplate geometry improves cable management by directing patch cords away from the panel face at a consistent angle, reducing strain on connector interfaces and keeping cable runs organized in high-density rack environments. Installation is performed by low-voltage cabling technicians.

This panel is suited for commercial and enterprise network infrastructure applications where port density and cable management are critical. The field-configurable design makes it a practical choice for new installations as well as retrofit projects where connector type requirements may vary across zones. It ships as a single unit and mounts in a standard 19-inch equipment rack or cabinet.

Key Features

• 48-port capacity supports high-density structured cabling deployments
• Field-configurable insert design allows technicians to specify connector type on site
• Angled faceplate directs patch cords for improved cable management and reduced congestion
• Blank panel base ships ready to accept modular keystone or snap-in inserts
• Standard rack-mount form factor fits 19-inch cabinets and open-frame racks

Compatibility

Designed as a field-configurable modular patch panel for use in standard 19-inch equipment racks and telecommunications enclosures. Specific compatible insert modules or system families were not identified in the available product data.

Installation Notes

Installation is performed by qualified low-voltage cabling technicians in accordance with applicable structured cabling standards such as ANSI/TIA-568. De-energize any adjacent active equipment and follow proper ESD precautions before handling modular inserts. Secure the panel to the rack using appropriate mounting hardware before inserting or terminating modules. Do not exceed the panel port count when populating inserts.
