Signamax 065-1100 10/100BaseT/TX to 100 Base FX Media Converter ST/MM

Product Description

The Signamax 10/100BaseT/TX to 100 Base FX Media Converter, model 065-1100, supports Link Fault Signaling. This feature enables an SNMP managed switch to detect issues in fiber or twisted-pair connections. In case of failure, the switch can reroute to a backup path if it is equipped with Spanning Tree Algorithm. This function enhances the operation of managed switches and contributes to fail-safe network designs.

These media converters can extend singlemode fiber distances over 46 miles with specific configurations. The integrated 10/100 switch allows connections at 100 Mbps to either a 10BaseT or a 100BaseTX network while ensuring compliance with the 100BaseFX standard. The fiber connection supports full duplex mode, regardless of whether the RJ-45 port is linked to a full duplex switch or half duplex hub. The built-in switch segregates the network, facilitating the longest possible fiber distance.

• Supports Link Fault Signaling for reliable network management
• Operates over 46 miles with singlemode fiber
• Dual mode operation for versatile connectivity options

Product Highlights

This media converter is essential for the reliable performance of complex networking systems.

Product Information

Standard Information

• Brand: Signamax
• Manufacturer: Fiber Instrument Sales, Inc.

Technical Specifications

• MPN: 065-1100
• Weight: 5.28 oz
• Dimensions: 4.3 inches (D) x 3.2 inches (W) x 0.9 inches (H)
• Operating Temperature: 32 to 122 degrees Fahrenheit
• Latency: Less than 4.2 microseconds
• Power Supply: AC, DC
• Network Technology: 10/100Base-TX, 100Base-FX
• Wavelength: 1300 nm
• Distance Supported: 1.24 Miles
