Sigma 811009612 90 Degree Reducing Elbow 1-1/2x1-1/4 Fnpt 150lb

Product Description

The SIGMA 811009612 is a FIG 3101R 90-degree reducing pipe elbow rated at 150 lb, manufactured from galvanized malleable iron. It transitions from a 1-1/2 inch nominal inlet to a 1-1/4 inch nominal outlet using female NPT (FNPT) threaded connections on both ends. The galvanized finish provides corrosion resistance for use in standard pipe systems. This fitting is installed by licensed plumbers, pipefitters, and mechanical contractors working on threaded piping assemblies in commercial and residential applications where a direction change and pipe size reduction are needed at the same point in the run.

This reducing elbow is suited for low-pressure threaded pipe systems including water distribution, general plumbing, and light industrial piping. The 90-degree geometry handles a right-angle turn while simultaneously stepping down pipe size, eliminating the need for a separate reducer fitting. The FNPT end style accepts standard tapered male NPT pipe threads, making it compatible with conventional threaded pipe and fittings across the trade.

Key Features

• 90-degree turn with integral pipe reduction in a single fitting
• 150 lb pressure class rating for standard-service threaded piping
• FNPT connections on both ends accept standard tapered male NPT threads
• Malleable iron construction offers strength and resistance to mechanical stress
• Galvanized finish adds corrosion protection for wet or exposed environments

Compatibility

Designed as an OEM-style replacement or new-installation fitting for 1-1/2 inch to 1-1/4 inch nominal threaded pipe systems using standard NPT connections rated to 150 lb class.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable plumbing codes such as the IPC. Shut off and depressurize the pipe system completely before disassembling or installing any threaded fitting. Apply an approved thread sealant or PTFE tape to the male threads before assembly, and tighten with a pipe wrench to a snug, leak-free connection. Do not overtighten malleable iron fittings, as the material can crack under excessive torque.

Technical Specifications

• Figure Number: FIG 3101R
• Fitting Type: 90 Degree Reducing Elbow
• Inlet Size: 1-1/2 inches nominal
• Outlet Size: 1-1/4 inches nominal
• End Style: FNPT (Female National Pipe Taper)
• Pressure Rating: 150 lb
• Material: Malleable Iron
• Finish: Galvanized

Standard Information

• Brand: SIGMA
• Manufacturer Part Number: 811009612
