Siemens WP4312RJ UNI-PAK 3-Position Meter Socket, 120/240 VAC, 400 A, 1 Phase

Product Description

The Siemens WP4312RJ UNI-PAK is a 3-position meter socket designed for 120/240 VAC, 400 A, 1 Phase systems. Suitable for service entrance equipment and small buildings, it features individual split covers and a barriered, sealable compartment. The meter socket is pre-bussed for easy installation and wiring. It is designed with aluminum/copper lay-in lugs and offers bottom and rear branch wiring exits.

• Features individual split covers with barrel lock compatibility
• Completely self-contained meter centers
• Compact, pre-bussed, easy to handle, hang and wire

Product Highlights

The Siemens WP4312RJ meter socket is a compact, pre-bussed, and self-contained solution for multi-metering applications. It is suitable for service entrance and small building applications.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: WP4312RJ
• Country of Origin: US

Technical Specifications

• Voltage Rating: 120/240 VAC
• Number of Jaws: 5
• Amperage Rating: 400 A
• Mounting Type: Surface
• Type: 3-Position
• Feed Type: Bottom/Top
• Cover Type: Ringless
• Phase: 1
• Series: WP Series
• Wire Size: 1/0 to 3/0 AWG, 1/0 AWG to 250 kcmil, 1/0 AWG to 750 kcmil
• Vendor SKU: WP4312RJ
• UPC: 040892875751
• Application: Service Entrance Equipments, Small Apartment Buildings, Small Professional and Commercial Buildings Applications
• Standard & Approvals: UL 50|UL 67|UL 414
• Manufacturer: Siemens
• Brand: Siemens
• Special Features: 100 kA interrupt rating 200 A sockets feed plug-in tenant breakers through 225 A 3-wire connection Aluminum/copper lay-in lugs, except two position 125 A units ANSI NO 61 light gray electro-deposited paint on zinc coated steel Available with horn bypass factory installed Barriered, sealable compartment for unmetered current carrying parts Bottom and rear branch wiring exits (neutral and ground at bottom only) Compact, pre-bussed, easy to handle, hang and wire Completely self-contained meter centers Individual split covers with barrel lock compatibility QP, QPH, HQP, MP-T, MP-HT, MP-MT, QS, QSH, QSHH, HQS, HQSH breaker provision
• Mounting: SURFACEMOUNTING
• Mounting_Type: Wall
• Standard: UL50/UL67/UL414
• Sub_Brand: Uni-PAK
